WestLake Tires Philippines

CL991

Size	LR / PR	Tread Depth (mm)	Standard Rim	Overall Diameter (mm)	Section Width (mm)	Max. Load Capacity at Cold Inflation Pressure SINGLE (kg)	Max. Load Capacity at Cold Inflation Pressure DUAL (kg)
9.00-20	H/16	26.0	7.00	1038	259	2900	2500
9.00-20	H/16	28.0	7.50	1073	278	3000	2650
10.00-20	J/18	28.0	7.50	1073	278	3350	2900
11.00-20	H/16	30.0	8.00	1105	293	3350	2900
11.00-20	J/18	30.0	8.00	1105	293	3650	3150
12.00-20	J/18	30.0	8.50	1145	315	3750	3350
12.00-24	L/20	30.0	8.50	1145	315	4000	3450
