AZ850

Multiple gripping edges slice through water and road films for a solid grip
Four wide continuous rib design help resist tread squirm and heel-and-tow wear for exceptionally long tread life
Three circumferential grooves help deliver all-season traction on wet or dry road
Closed shoulder design helps promote even wear throughout the tyre life

Size	LR/PR	Service index	Tread Depth (mm)	Standard Rim	Overall Diameter (mm)	Section Width (mm)	SINGLE (Kg)	SINGLE (kPa)	DUAL (Kg)	DUAL (kPa)
7.00R16	H/16	128/124L	15.0	6.50H	855	235	1800	770	1600	770
8.25R20	H/16	139/137K	15.0	6.5	974	236	2430	930	2300	930
9.00R20	H/16	144/142K	15.5	7.0	1019	259	2800	900	2650	900
10.00R20	J/18	149/146J	15.5	7.5	1054	278	3250	930	3000	930
11.00R20	J/18	152/149K	16.5	8.0	1085	293	3550	930	3250	930
12.00R20	J/18	154/151K	17.5	8.5	1125	315	3750	830	3450	830
12.00R20	M/22	158/155J	17.5	8.5	1125	315	4250	900	3875	900
11R22.5	J/18	149/146L	17.0	8.25	1065	279	3250	930	3000	930
12R22.5	J/18	152/149L	18.0	9.00	1085	300	3550	930	3250	930
11.00R20	J/18	152/149M	16.0	8.0	1085	293	3550	930	3250	950
13R22.5	J/18	156/151K	20.0	9.75	1124	320	4000	875	3450	875
295/80R22.5	J/18	152/149M	18.0	9.00	1050	298	3550	900	3250	900
